Tiger Claw TC-3S Composite Hidden Deck Fasteners
Product Description
Heavy Gauge Stainless steel fastener with black oxide coating to better hide fastener between boards.
Product Requirements
When using Tiger Claw fasteners please review and comply with these requirements to obtain proper installation. Failure to follow these requirements may result in deck failure and/or void of warranty. Inspect decking material prior to installation. Omit any planks that contain hooks, twists, splits, cracks, or other defects. Always install decking with the crown upward.
When Using
Fastener provides an automatic 3/16" spacing, but will accommodate up to 5/16". We recommend spacing according to the decking manufacturer specifications. Check the decking manufacturer’s installation guide for spacing details. If decking is less than 15/16" in thickness, pre drilling may be required. Test fasteners in decking before installation begins.
Product Features and Compatibility
Developed specifically for use with composite or synthetic decking materials and medium density mahogany.
TC-3S will work in the following composite and synthetic decking lumber varieties:
- Boardwalk
- ChoiceDek
- Elements
- EverGrain
- EverX
- Fiberon
- GeoDeck
- Green Tree (2x4 hollow)
- Latitude
- Monarch
- Portico
- Trex
- UltraDeck
- Veranda
- Weather Best
- WeatherShield
- Ameridek
- Moisture shield
- Medium Density Mahogany
- PVC decking with hard outer shell coat
TC-3S will work in the following medium density hardwood decking lumber varieties:
- Cambara
- Meranti
- Medium Density Mahogany
Please consult your composite manufacturer or ask us first if you plan to use any other composite or synthetic material not listed above in your decking project.
TC-3S should NOT be used with the following types of decking:
- Correct Deck
- Ironwoods
- Oasis
- Pressure Treated
- Supreme Decking
- TimberTech 2"x6" hollow plank
PLEASE NOTE:
Medium density hardwood decking, (ie; Mahoganies like Meranti and Cambara) are types of material that are more susceptible to movement depending on the climate in which it is used. Altitude, moisture content, humidity, and temperature are some factors to consider when selecting the proper gap for these types of decking material. Consult with your lumber provider to determine how the material will react to climate changes in your particular area and application. The TC-3 fastener is designed to better hand movement in these types of materials.
* TC-4S fasteners should not be used with these types of decking.
